Salpido

SAL-PWB202

SAL-PWB202

50 in stock

RM69.00

RM69.00

Sale

Color: Black

Battery Capacity 20000mAh

Quantity

Description & Specification

Model: SAL-PWB202
Capacity: 20000mAh
Input voltage: 4.8V - 5.5V
Fast charge input voltage: 8.8 - 9.2V
Input current: 2000mA
Charge cut-off current: ≤ 60mA
USB continuous output current: 2000mA
Charge voltage: 3.0~4.2V
Output voltage: 5.0~5.25V
Output current: IOUT = 3.0A
Boost efficiency: Vbat>4.0V; I=3.0A
Output no-load voltage: 4.8-5.3V/ 8.8-9.3V/ 11.8-12.3V
Output load voltage: 4.75-5.2V/ 8.75-9.2V/ 11.75-12.2V
Output ripple: ≤ 200mV
Cell charging cut-off voltage: 4.2V - 4.30V
Cell discharge cut-off voltage: 2.5 - 3V
Self-consumption current: ≤ 100uA
Efficiency at USB output 1A: 82% - 87%
Operating temperature: -10℃—— 60℃
Storage temperature: -25℃—— 45℃
Relative humidity: ≤ 90%RH
Short circuit protection: Yes
